Reference Number: 134828

 KAUKAUNA UNIVERSAL RADIAL DRILL ON BED,
 MODEL: #140U, NEW 1953

 SPECIFICATIONS:
 DRILLING AREA ......................... 84" X 144"
 SPINDLE DIAMETER ...................... 4"
 DRILLING CAPACITY ..................... 3"
 MORSE TAPER IN SPINDLE NOSE ........... NO. 6MT
 SPINDLE TRAVEL ........................ 18"
 COLUMN DIAMETER ....................... 22"
 REACH-CENTER ON SPINDLE TO CENTER
     OF COLUMN, SPINDLE VERTICAL ..... 106"
 DISTANCE CENTER OF
     HORIZONTAL SPINDLE TO FLOOR:
     MAX. ............................ 163"
     MIN. ............................ 79"
 DISTANCE - NOSE OF VERTICAL
     SPINDLE TO FLOOR:
     MAX. ............................ 108"
     MIN. ............................ 6"
 HORIZONTAL TRAVEL - COLUMN ON RUNWAY .. 144"
 TRAVERSE RATE ON RUNWAY ............... 80 IPM
 VERTICAL TRAVEL OF HEAD ON COLUMN ..... 84"
 TRAVERSE RATE ON COLUMN ............... 80 IPM
 TRAVERSE OF HEAD & RAIL ON RAIL SLIDE . 36"
 TRAVERSE RATE OF RAIL ................. 60 IPM
 SWIVEL OF HEAD ON TRUNNION ............ 360º
 SWIVEL OF TRUNNION ON RAIL ............ 180º
 COLUMN SWIVEL ......................... 360º
 HEIGHT OF RUNWAY ...................... 161/2"
 LENGTH OF RUNWAY ...................... 18'
 WIDTH OF RUNWAY ....................... 56"
 SPINDLE SPEEDS (9) .................... 35 TO 600 RPM
 SPINDLE FEEDS (9) ..................... .0035 TO .062 IPR
 HEIGHT OVER COLUMN CAP ................ 20' 6"
 APPROX WEIGHT ......................... 60,000 LBS.

 EQUIPPED WITH:
 HARDENED REPLEACEBLE BEDWAYS
 96" EXTRA COLUMN TRAVEL ON BED
 24" EXTRA VERTICAL TRAVEL ON COLUMN
 LIFTING EAR ON TOP OF COLUMN CAP. FOR PORTABLE USE
 ELECTRIC CLAMPING OF COLUMN SWIVEL
 POWER CLAMPING TO ALL MOVEMENTS
 POWER RAPID TRAVERSE
 RACK AND PINION DRIVES, VERTICAL+HORIZONTAL
 PENDANT CONTROL
 10 H.P. 3/60/220-440 VOLT, 1740 RPM SPINDLE DRIVE
 MOTOR W/CONTROLS
 MACHINE WIRED FOR 3/60/440 OPERATION
