Reference Number: 138066

New Heck Bevel Mill Pro-Series
 High Production Beveling Machine
 Model: Pro 12

 Features:
 Self Propelled
 Hands Free Beveling
 Variable Angle
 Simple, Quiet Operation
 Shear Type Cutting
 Sharpenable Cutters
 Use Bench Mounted, on Casters or Suspend from Overhead Crane
 By inverting, bottom edges can also be worked
 Work Mild Steel, Stainless or Aluminum up to 1-3/4"
 Available: Narrow width attachment works strips as narrow as 7/8"

 Specifications:
 MAXIMUM BEVEL (30 Degrees) - 1/2" one pass, 5/8" two passes
 MAXIMUM PLATE THICKNESS - 1-1/2"
 MINIMUM PLATE THICKNESS - 3/16"
 MINIMUM PLATE WIDTH - Standard 2"
 FEED RATE - 10' per minute
 MOTOR - 3 HP, 220V, Single Phase - 220/440/575V 3 Phase
 SIZE (L x W x H) - 20" x 14" x 26"
 WEIGHT: 145 LBS

 OPTIONAL ACCESSORIES (call for pricing):
 Cutter for mild steel
 Cutter for hard material
 Cutter for aluminum
 Cutter for finishing up to 5/16" thick
 Roller 30 degree
 Roller 37-1/2 degree
 Roller 45 degree
 Narrow width attachment 30 degree, 7/8" min.
 Narrow width attachment 45 degree, 1-1/2" min.

 *Machine includes 30-degree roller assembly, mild steel
 cutter, wrenches and instructions. 220 or 440 Volt 3 Phase.
