Reference Number: 138075
New Heck Hydraulic NotcherPrice: $11,390
Fixed Angle
Model: 2006FA
Features:
Automatic blade clearance adjustment
Solid brass scales with multiple graduations for quick and easy set up
Step notching for large and special cut-outs
Ability to stop the ram during the cycle for additional flexibility
Two heavy duty side gauges hardened and ground with protractors and
preset pins every 45°
Graduated internal stop for shearing
Optional disappearing stops for step notching
Large work table
Large capacity hydraulic reserve
Specifications:
Blade Length: 8"
Angle: 90 Degree Fixed
Capacity, Mild Steel: 1/4" (.250)
Capacity, Stainless Steel: .157"
Motor: 5.3 HP, 220/440V
Strokes Per Minute: 40
Oil Tank: 13 Gallons
Table Size: 37" x 24-1/2"
Size (W x D x H): 38-1/2" x 34-1/2" x 41-1/2"
WEIGHT: 1,300 LBS
