Reference Number: 142626

14" JONES & LAMSON FLOOR MODEL HORIZONTAL PROJECTION
  OPTICAL COMPARATOR

 MODEL: FC-14     S/N: E-25056     NEW: 1965

  SCREEN DIAMETER ................................... 14"
 TABLE SIZE ................................... 6" X 30"
 MEASURING CAPACITY (TABLE TRAVEL):
 LONGITUDINAL ....................................... 8"
 VERTICAL ........................................... 5"
 ANGULAR MEASURING CAPACITY .... 360 DEG. CHART ROTATION
 CROSS TRAVEL FOR FOCUSING ...................... 1.375"
 HELIX ADJ. - TABLE SWIVELS, LEFT OR RIGHT ..... 15 DEG.

 FLOOR SPACE ................... 33"LR X 56"FB X 78"HIGH
 APPROXIMATE WEIGHT .......................... 1,300 LBS

  EQUIPPED WITH:
 HORIZONTAL PROJECTION
 MERCURY ARC NOVALITE HIGH INTENSITY LIGHTING
 ERECT IMAGES & FIXED FOCAL PLANE @ ALL MAGNIFICATIONS
 J & L REFLECTION ATTACHMENT (SURFACE ILLUMINATION)
 (3) LENSES, 10X, 20X, & 50X
 6-POSITION POWER LENS TURRET
 MANUAL TABLE TRAVERSE
 MANUAL TABLE ELEVATION
 LARGE VISOR W/CURTAIN
 J&L ROTARY STAGE
 MATCHING PAIR OF J & L TAILSTOCKS WITH 5- 1/2" SWING CAP.
 J & L BLOCK, 6" LONG x 2- 1/4"W x 1- 5/8"H
 J & L BLOCK, 4" LONG x 2- 1/4"W x 1- 5/8"H
 SINGLE PHASE/60 CYCLE/118 VOLT ELECTRICS

  ** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE **
 *** EXCELLENT CONDITION & APPEARANCE ***
