Watch Video:

Bridgeport 3-Axis SMX Proto-Trak / J Head CNC VERTICAL MILLING MACHINES

$9,950

Make:
Bridgeport
Model:
3-Axis SMX Proto-Trak / J Head
Year:
2000's
Ref #:
174580

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


BRIDGEPORT PROTO-TRAK 3-AXIS CNC VERTICAL MILL
MODEL: W/SMX CONTROL
  S/N: 12/BR 177291, UPDATED IN 2022

SPECIFICATIONS:
WORKING SURFACE OF TABLE ................. 9" x 48"
LONGITUDINAL TABLE TRAVEL ................ 30"
CROSS TABLE TRAVEL ....................... 12"
QUILL TRAVEL ............................. 5"
KNEE TRAVEL .............................. 16"
SPINDLE SPEEDS (8) ....................... 80 - 2,720 R.P.M.
SPINDLE TAPER ............................ R-8
HEAD TILT, LEFT & RIGHT .................. 90 DEGREES
HEAD TILT, FRONT TO REAR ................. 45 DEGREES
FLOOR SPACE: ............................. 60" x 63" x 82"
WEIGHT APPROXIMATELY: .................... 2,400 LBS.

EQUIPPED WITH:
SOUTHWESTERN INDUSTRIES PROTOTRAK CONTROL UPDATED IN 2022
 MODEL: SMX 3-AXIS CNC SYSTEM
   WITH SERVO MOTORS, MANUAL DATA INPUT 2 AXIS
   LINEAR & CIRCULAR INTERPOLATION, PROGRAM DOWNLOAD,
   MIRROR IMAGE, PART GRAPHICS,
IN MANUAL OPERATION, CONTROL BECOMES 3 AXIS DIGITAL READOUT
REMOTE GO SWITCH
GROUND BALLSCREWS ON TABLE & SADDLE
CHROME WAYS
BIJUR LUBRICATION SYSTEM
1 HORSE POWER MAIN MOTOR

TRANSITION FREELY FROM 3-AXIS CNC TO MANUAL
PERFECT FOR A TOOLROOM OR PROTO-TYPE WORK

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE


DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
