Clausing 2285 MULTI-SPINDLE & PRODUCTION DRILLS

$3,950

Make:
Clausing
Model:
2285
Year:
1990
Ref #:
159918

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


20" 2-SPINDLE CLAUSING VARIABLE SPEED
MULTI-SPINDLE DRILL
MODEL: 2285  S/N:527250 & 527521, MFG: 1990

SPECIFICATIONS:
DRILL TO CENTER OF CIRCLE................ 20"
THROAT SPINDLE TO COLUMN................. 10"
SPINDLE TRAVEL........................... 6-1/2"
SPINDLE TAPER............................ #3 MT
DRILLING CAPACITY ....................... 1-1/4"
COLUMN DIAMETER.......................... 4"
DISTANCE BETWEEN SPINDLE CENTERS ........ 20"
MAXIMUM HEIGHT UNDER SPINDLE ............ 25-7/16"
WORKING SURFACE OF TABLE................. 40" x 24"
OVERALL TABLE SIZE WITH COOLANT THROUGH.. 45-1/2"W x 29-1/2"D
SPINDLE SPEEDS VARIABLE ................. 150 - 2000 RPM
APPROXIMATE WEIGHT ...................... 1750 LBS.

EQUIPPED WITH:
  - T-SLOTTED PRODUCTION TABLE WITH COOLANT TROUGH
  - RAISING & LOWERING OF HEADS THRU ELEVATING SCREW
   MECHANISM
  - 1.5 HORSE POWER SPINDLE MOTORS

CONDITION: ****  EXCELLENT  ****


DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
