Dahlih DL-GH2200 VERTICAL MILLS - VERTICAL MILLING MACHINES

Price on Request

Make:
Dahlih
Model:
DL-GH2200
Year:
1982
Ref #:
162432

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


DAHLIH COMBINATION VARIABLE SPEED
TURRET TYPE VERTICAL AND HORIZONTAL MILL
MODEL: DL-GH2200,  S/N: 80658, YEAR: 1982

SPECIFICATIONS:
TABLE WORKING SURFACE: ..................... 13-1/4" x 51-1/8"
RANGE: LONGITUDINAL: ....................... 34"
CROSS: ..................................... 12"
VERTICAL (KNEE): ........................... 16"
TAPER IN HORIZONTAL SPINDLE: ............... N.S.T. 40
HORIZONTAL SPINDLE SPEEDS: (9) ............. 90 - 1400 RPM
LONGITUDINAL & CROSS FEEDS: (12) ........... .6" - 28 IPM
TAPER IN VERTICAL SPINDLE: ................. N.S.T. 40
QUILL TRAVEL: .............................. 6".
POWER QUILL FEEDS: (3) ........ 0.0014, 0.0028, 0.0056 IPR
HEAD SWIVELS: .............................. ± 45º
INF VAR VERT SPINDLE SPEEDS: ............... 80 - 3800 RPM
HORIZ TRAVEL OF RAM: ....................... 20"
SWIVEL OF RAM: ............................. 360º
APPROX WEIGHT: ............................. 5,500 LBS.
APPROX DIMENSIONS: ......... 75" L-R x 83" F-B x 93-1/2"H

EQUIPPED WITH:
- VARI-SPEED VERTICAL HEAD MOUNTED ON SWIVEL RAM
- PUSH BUTTON, AIR OPERATED POWER DRAW BAR
- HORIZONTAL SPINDLE
- POWER RAPID TRAVERSE
- POWER ELEVATION OF KNEE
- COOLANT
- SWING PENDANT CONTROL
- ARBOR SUPPORT
- 40 TAPER ARBOR
- 5 H.P. VERTICAL SPINDLE DRIVE
- 5 H.P. HORIZONTAL SPINDLE DRIVE

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE

DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
