Dahlih DL-GH950 VERTICAL MILLS - VERTICAL MILLING MACHINES

Price on Request

Make:
Dahlih
Model:
DL-GH950
Year:
1985
Ref #:
162433

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


DAHLIH COMBINATION VARIABLE SPEED
TURRET TYPE VERTICAL AND HORIZONTAL MILL
MODEL: DL-GH950,  S/N: 85001, YEAR: 1985

SPECIFICATIONS:
TABLE WORKING SURFACE: ..................... 12" x 53"
RANGE: LONGITUDINAL: ....................... 34"
CROSS: ..................................... 12"
VERTICAL (KNEE): ........................... 16"
TAPER IN HORIZONTAL SPINDLE: ............... N.S.T. 40
HORIZONTAL SPINDLE SPEEDS: (12) ............ 50 - 1485 RPM
LONGITUDINAL & CROSS FEEDS: (12) ........... .5 - 42 IPM
KNEE FEEDS: (12) ........................... .2 - 16 IPM
TAPER IN VERTICAL SPINDLE: ................. N.S.T. 40
QUILL TRAVEL: .............................. 6"
POWER QUILL FEEDS: (3) ........ 0.0014, 0.0028, 0.0056 IPR
HEAD SWIVEL: ............................... ± 45º
INF VAR VERT SPINDLE SPEEDS: ............... 80 - 3800 RPM
HORIZ TRAVEL OF RAM: ....................... 20"
SWIVEL OF RAM: ............................. 360º
APPROX WEIGHT: ............................. 5,500 LBS.
APPROX DIMENSIONS: ......... 75" L-R x 83" F-B x 93-1/2"H

EQUIPPED WITH:
- VARI-SPEED VERTICAL HEAD MOUNTED ON SWIVEL RAM
- AIR ACTUATED POWER DRAW BAR
- HORIZONTAL SPINDLE
- POWER RAPID TRAVERSE
- COOLANT
- MITUTOYO 3-AXIS DIGITAL READ OUT
- SWING PENDANT CONTROL
- ARBOR SUPPORT
- 40 TAPER ARBOR
- 2 HORSE POWER TABLE FEED
- 5 HORSE POWER VERTICAL SPINDLE DRIVE
- 5 HORSE POWER HORIZONTAL SPINDLE DRIVE

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
