Deckel FP2 HORIZONTAL MILLING MACHINES w/ UNIVERSAL TABLE

$9,950

Make:
Deckel
Model:
FP2
Year:
1970'S
Ref #:
160099

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


DECKEL UNIVERSAL HORIZONTAL/VERTICAL MILL
MODEL: FP-2,   S/N: 8786

SPECIFICATIONS:
NUMBER OF SPINDLE SPEEDS .............. 18
SPINDLE SPEEDS ........................ 40 - 2000 R.P.M.
SPINDLE HORSE POWER ................... 3
RATIO BETWEEN ANY TWO CONSECUTIVE
  SPINDLE SPEEDS ...................... 1.25:1
RATIO BETWEEN MINIMUM & MAXIMUM
  SPEEDS ............................. 1:50
TAPER HOLE IN SPINDLE NOSE ........... STD NO. 40 TAPER
HEADSTOCK HORIZONTAL TRAVEL, POWER
  OPERATED/MANUAL .................... 7.5/8" (190mm)
BEARING SLEEVE, ONE REVOLUTION OF
  OF SCALE DRUM EQUALS ............... 0.5" (12.7mm)
BEARING SLEEVE, ONE SCALE DRUM
  DIVISION EQUALS .................... 0.01" (.254 mm)
KNEE TABLE WORK CLAMPING AREA ........ 28-5/8" x 9-7/16"
FIXED ANGULAR TABLE CLAMPING AREA .... 28" x 13" (711x330mm)
WORKTABLE LONGITUDINAL TRAVEL ........ 15.75" (390 mm)
WORKTABLE VERTICAL TRAVEL ............ 15.75" (390 mm)
NUMBER OF FEEDS ...................... 18
FEED RATES ........................... 0.3 - 16 IN. PER MIN.
POWER RAPID TRAVERSE RATE ............ 45"/min (1,143 mm)
WORKTABLE HORIZONTAL FEEDSCREW, ONE
  REVOLUTION OF SCALE DRUM EQUALS .... 0.10" (2.5 mm)
WORKTABLE ELEVATING SCREW, ONE
  REVOLUTION OF SCALE DRUM EQUALS .... 0.10" (2.5 mm)
HEADSTOCK FEEDSCREW, ONE REVOLUTION
  OF SCALE DRUM EQUALS ............... 0.10" (2.5 mm)
ONE SCALE DRUM DIVISION EQUALS ....... 0.001" (0.0254mm)
LxW OF MACHINE ....................... 56-5/16" x 68-1/2"
OVERALL HEIGHT OF MACHINE, EXCL.
  ATTACHMENT ......................... 55-1/8"
OVERALL HEIGHT INCL. HIGH SPEED
  VERTICAL SPINDLE HEAD .............. 71"
FLOOR SPACE .......................... 82-11/16" x 94-1/2" IN.
NET WEIGHT OF MACHINE INCL. ELECTRICAL
  CABINET ............................ 2,425 LBS.

EQUIPPED WITH:
LARGE ANGULAR TABLE
VERTICAL HEAD
ARBOR SUPPORT
MISCELLENOUS TOOLING
3 HORSE POWER SPINDLE MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
