DoAll 1612-H VERTICAL BAND SAWS

Price on Request

Make:
DoAll
Model:
1612-H
Year:
1969
Ref #:
161684

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


16" DO ALL VERTICAL BAND SAW
MODEL 1612-H,  S/N: 288-69106, MFG: 1969

SPECIFICATIONS:
THROAT CAPACITY, BAND TO COLUMN ....... 16"
MAX WORK HEIGHT ....................... 12"
BAND WIDTH CAPACITY ................... 1/16" - 1"
FILE/BAND LENGTH ...................... 123"/125"
TABLE SIZE ............................ 24" X 30-1/2"
TABLE TILT, MANUAL .................... 45 DEG RT, 10 DEG LT
TABLE STROKE .......................... 12"
INF VARIABLE BLADE SPEEDS ............. 50 - 5,200 F.P.M.
INF VAR HYDRAULIC FEED RANGE .......... 0 - 12 F.P.M.
INF VAR HYDRAULIC FEED FORCE RANGE .... 0 - 350 LBS.
NUMBER OF 9/16" T-SLOTS IN TABLE ...... 2
WEIGHT CAPACITY OF TABLE,
    EVENLY DISTRIBUTED .............. 1,000 LBS.
APPROX WEIGHT ......................... 1,750 LBS.
APPROX DIMENSIONS:
F-B ............................. 46"
L-R ............................. 48"
HEIGHT .......................... 78"

EQUIPPED WITH:
HYDRAULIC TABLE FEED WITH MANUALLY OPERATED FOUR-POSITION (FORWARD/REVERSE/STOP/FEED)
         DIRECTIONAL CONTROL LEVER AND VERNIER FOR CONTROL OF FEED SPEED
TWO SPEED TRANSMISSION
DO-ALL MODEL:DBW-15 BUTT WELDER, GRINDER, AND BLADE SHEAR
AIR PUMP AND CHIP BLOWER
1/3 H.P. 3/60/220-440 VOLT HYDRAULIC PUMP MOTOR
2 H.P. 3/60/220-440 VOLT BLADE DRIVE MOTOR AND ELECTRICAL CONTROLS

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
