Watch Video:

Fadal 3016L VERTICAL MACHINING CENTERS. VMC's

$15,500

Make:
Fadal
Model:
3016L
Year:
2001
Ref #:
161118

Or call us for a quote at (973) 497-7500 or send us an email at cncmachines@machineryvalues.com


FADAL CNC VERTICAL MACHINING CENTER
MODEL: 3016L,  S/N: 012001012005,  YEAR: 2001

SPECIFICATIONS:
X AXIS TRAVEL ............... 30"
Y AXIS TRAVEL ............... 16"
Z AXIS TRAVEL ............... 20"
SPINDLE SPEED ............... 75 - 7,500 RPM
SPINDLE HORSE POWER ......... 7.5 HP
SPINDLE TAPER ............... Cat 40
SPINDLE NOSE to TABLE  ...... 4" - 24"
SPINDLE C/L TO COLUMN WAYS .. 16"
ATC NUMBER OF TOOLS ......... 21
ATC TOOL SELECTION .......... Randon/Bi-directional
MAX. TOOL WEIGHT ............ 15lbs.
TABLE SIZE .................. 38" x 16"
FLOOR TO TABLE SURFACE ...... 30"
CUTTING FEEED RATE (X/Y/Z) .. 01"-250"
RAPID FEED RATE (X/Y) ....... 700ipm 600ipm (Z)
MAX WEIGHT on TABLE ......... 1,000 lbs

MACHINE WIDTH x DEPTH ....... 90"W x 90"D
MACHINE HEIGHT .............. 94"
MACHINE WEIGHT .............. 8,300 lbs.

EQUIPPED WITH:
FADAL MODEL: 88 MULTI PROCESSOR CONTROL
EXPANDED MEMORY
RIGID TAPPING
FADAL MODEL: VH5C FOURTH AXIS
FULL ENCLOSURES
FLOOD COOLANT

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE

DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
