Hardinge DSM-59 SECOND OPERATION LATHES

$6,500

Make:
Hardinge
Model:
DSM-59
Year:
1987
Ref #:
160209

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com


HARDINGE SECOND OPERATION LATHE,
MODEL: DSM-59,  S/N: DV-59-18638, NEW: 1987

SPECIFICATIONS:
SPINDLE CAPACITY WITH ROUND 5C COLLETS .. 1-1/16"
HEXAGON 5C COLLETS ...................... 7/8"
SQUARE 5C COLLETS ....................... 3/4"
STEP CHUCKS ............................. 1-1/16" TO 6"
JAW CHUCKS .............................. 5"
JAW CHUCKS THROUGH SPINDLE .............. 1-5/32"
SPINDLE NOSE ............................ 2-3/16" - R.H.
LENGTH OF BED ........................... 36"
SWING OVER BED .......................... 9"
TRAVEL OF DOUBLE TOOL CROSS SLIDE ....... 3-3/4"
TRAVEL OF TURRET SLIDE .................. 4"
DIAMETER OF TURRET HOLES ................ 5/8"
VARIABLE SPINDLE SPEED RANGE ............ 230 TO 3,500 RPM
APPROXIMATE WEIGHT ...................... 1,100 LBS.

EQUIPPED WITH:
- HEXAGON TURRET
- DOUBLE TOOL CROSS SLIDE
- TOOL BLOCK
- MISCELLENEOUS COLLETS
- PUSH BUTTON CONTROL FOR VARIABLE SPEED
- BALL BEARING LEVER COLLET CLOSER WITH 5C COLLETS
- SELF-CONTAINED COOLANT SYSTEM WITH PUMP
- 3/4-3/8 H.P. 3/60/230 VOLT TWO-SPEED MAIN DRIVE MOTOR
AND ELECTRICAL CONTROLS

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
