Toyoda GUP-32x50, 1981, I.D. ATT., FULL AUTO CYCLE, UNIVERSAL CYLINDRICAL GRINDERS

Price on Request

Make:: Toyoda

Model:: GUP-32x50, 1981, I.D. ATT., FULL AUTO CYCLE,

Year:: 1981

Ref #:: 164417

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

         12.6" X 20" TOYODA
          "MADE IN JAPAN"
UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER

MODEL:GUP32X50      S/N: RB5253      NEW: 1981

MAX. SWING OVER TABLE .................. 12.6"
DISTANCE BETWEEN CENTERS ............... 20"
MAX. LOAD BETWEEN CENTERS .............. 330 LBS.

TABLE:
TABLE SWIVELS, COUNTERCLOCKWISE ........ 12.5°
LONGITUDINAL TABLE TRAVERSE SPEED ...... 2" TO 157" IPM

WHEELHEAD:
WHEELHEAD SWIVELS LEFT & RIGHT ......... 30°
GRINDING WHEEL SIZE .................... 14" x 2" x 5"
WHEEL SPEEDS (2) ....................... 1650/2150 RPM
TOTAL STROKE ........................... 11.6"
HANDWHEEL INFEED STROKE ................ 6.3"
ADDITIONAL STROKE BY SLIDING ON
 SUB-SLIDE BASE ........................ 3.7"
AUTOMATIC RAPID INFEED STROKE .......... 1.6"
AUTOMATIC INFEED AT TABLE REVERSALS .... 0.0001" TO .0016"
AUTOMATIC PLUNGE INFEED ................ YES
AUTO PLUNGE INFEED W/POSITIVE STOP ..... 0 TO .0315"
MOVEMENT PER GRAD. OF HANDWHEEL ........ 0.0001"
MOVEMENT PER TURN OF HANDWHEEL ......... 0.040"

WORKHEAD:
WORKHEAD SWIVELS, COUNTERCLOCKWISE ..... 90°
                 CLOCKWISE ............. 30°
WORKHEAD SPINDLE TAPER ................. #4 MT
WORKHEAD, INFINITELY VARIABLE SPINDLE
 SPEEDS ................................ 16 TO 250 RPM

TAILSTOCK SPINDLE CENTER ............... #4 MT
TAILSTOCK QUILL TRAVEL ................. 1"

WEIGHT .............................. 6,840 LBS.
APPROX. MACHINE DIMENSIONS ...... 90" x 64"W x 57"H

MACHINE FEATURES:
TOYODA "STAT" HYDROSTATIC WHEELHEAD BEARINGS
FULLY AUTOMATIC GRINDING CYCLE FEATURING:
 HYDRAULIC TABLE TRAVERSE
 AUTOMATIC INFEED
 AUTOMATIC PLUNGE INFEED
 POWER RAPID WHEELHEAD ADVANCE & RETRACTION
 SPARKOUT TIMER
 ADJUSTABLE TABLE TARRY
EXTERNAL HYDRAULIC SYSTEM
DUAL LIVE/DEAD WORKHEAD SPINDLE
ELECTRICAL SYSTEM CONNECTED ON MACHINE (NOT SEPARATE)
MOTORS ARE FOR 3/60/220-440 VOLT ELECTRICS



EQUIPPED WITH:
  SWING DOWN I.D. GRINDING ATTACHMENT
  TOYODA I.D. SPINDLE.
  EXTERNAL COOLANT TANK
  MACHINE IS PRESENTLY WIRED FOR 3/60/220 VOLTS

Link to video: https://youtu.be/LCbwb6nxcww?si=MU9twLCNtb02pRYA


** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE  **
**  EXCELLENT CONDITION & APPEARANCE **
