Turn-Pro 89975494 EVS SECOND OPERATION LATHES

$5,950

Make:: Turn-Pro

Model:: 89975494 EVS

Year:: 2012

Ref #:: 178459

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

TURNPRO SECOND OPERATION LATHE
MODEL: 89975494,  S/N: 10103437,  NEW: 2012

SPECIFICATIONS:
SPINDLE CAPACITY WITH ROUND 5C COLLETS ... 1-1/16"
HEXAGON 5C COLLETS ....................... 7/8"
SQUARE 5C COLLETS ........................ 3/4"
STEP CHUCKS .............................. 1-1/16" TO 6"
JAW CHUCKS ............................... 5"
JAW CHUCKS THROUGH SPINDLE ............... 1-5/32"
SPINDLE NOSE ............................. HARDINGE TAPER
LENGTH OF BED ............................ 36"
SWING OVER BED ........................... 9"
TRAVEL OF DOUBLE TOOL CROSS SLIDE ........ 3-3/4"
TRAVEL OF TURRET SLIDE ................... 4"
DIAMETER OF TURRET HOLES ................. 5/8"
VARIABLE SPINDLE SPEED RANGE ............. 0 TO 4000 R.P.M.
APPROXIMATE WEIGHT ....................... 1,100 LBS.
APPROXIMATE DIMENSIONS ................... 68" x 30" x 58"

EQUIPPED WITH:
- ELECTRONIC VARIABLE SPEED CONTROL w/ DIGITAL TACHOMETER
- HEXAGON TURRET
- DOUBLE TOOL CROSS SLIDE
- LEVER-TYPE 5C COLLET CLOSER
- MISCELLENEOUS TURRET TOOLS
- COOLANT SYSTEM WITH PUMP MOTOR
- 3 H.P. 3/60/230 VOLT FRQUENCY CONTROLLED MOTOR

INSPECT UNDER POWER IN NEW JERSEY WAREHOUSE
