Betenbender 6-50-T PRESS BRAKES w/CNC BACK GAUGES

$24,500

Make:
Betenbender
Model:
6-50-T
Year:
2002
Ref #:
163842

Or call us for a quote at (973) 497-7500 or send us an email at presses@machineryvalues.com



6' X 50 TON BETENBENDER HYDRAULIC PRESS BRAKE
MODEL 6-50T            S/N 88602               NEW 2002

Capacity ................... 50 tons
Rated for material ......... 6' x 10 ga (mild steel)
                             4' x 3/16"
Overall length bed ......... 72"
Distance between housings .. 54.5"
Stroke ..................... 8"
Throat ..................... 8"
Die space - open ........... 14"
closed ..................... 6"
Bed width .................. 2"
Bed height ................. 28"
Ram speeds ................. 66 ipm approach
                             0-66 ipm forming (adjustable)
                             92 ipm return
Oil capacity ............... 33.5 gallons

Motor 10 hp / 230 / 460V
Approximate overall dimensions 91" W x 56" D x 90" H
Approximate weight 7,000 lbs.

Machine is equipped with:
- Model 94FOP24-GT swing arm pendant mounted 5-position digital "GO-TO" powered backgauge and ram positioner
- Remote operators pedestal w/ dual palm buttons and foot pedal
- (2) 24" front slotted support arms
- Adjustable tonnage w/ pressure gauge
- Lube system
- Hobbs hour meter
- Work light
- Lower die holder
- Upper ram clamps
- Adjustable dwell timer
- Manuals & schematics
- Hour meter shows 5,907 power on hrs.

*PRELIMINARY SPECIFICATIONS - SUBJECT TO VERIFICATION
FOB: GRAND RAPIDS, MI
