Bridgeport-Romi TORMAX 13-5 ENGINE LATHES

$10,950

Make:: Bridgeport-Romi

Model:: TORMAX 13-5

Year:: 1998

Ref #:: 167854

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

13" X 40" BRIDGEPORT-ROMI ENGINE LATHE
TORMAX 13-5, S/N: 002-084689-301,  NEW: 1998

SPECIFICATIONS:
SWING OVER BED .......................... 13"
SWING OVER CARRIAGE WINGS ............... 11-3/8"
SWING OVER CROSS SLIDE .................. 7-5/16"
DISTANCE BETWEEN CENTERS ................ 40"
BED WIDTH ............................... 8-7/8"
SPINDLE SPEED RANGE (12) ................ 50 - 2,500 R.P.M.
HOLE THROUGH SPINDLE .................... 1-9/16"
SPINDLE NOSE CAMLOCK .................... D1-4"
HEADSTOCK & TAILSTOCK SPINDLE TAPER ..... #3 MORSE
AMERICAN STANDARD THREADING RANGE (46) .. 4 TO 42 T.P.I.
METRIC THREADING RANGE (46) ............. 0.4 TO 7 MM
FEED CHANGES:
    LONGITUDINAL (20) ................... 0.00016 - .0287 IPR
    CROSS (20) .......................... 0.0007 - .0129 IPR
TAILSTOCK SPINDLE DIAMETER .............. 1-3/4"
TAILSTOCK SPINDLE TRAVEL ................ 4-3/4"
APPROXIMATE DIMENSIONS .................. 30"W x 80"L
APPROXIMATE WEIGHT ...................... 2600 LBS.


EQUIPPED WITH:
INDUCTION HARDENED AND GROUND BED WAYS
INCH AND METRIC THREADING CAPABILITY
MITUTOYO TWO AXIS DIGITAL READOUT
TAPER TURNING ATTACHMENT
6" 3-JAW CHUCK
8" 4-JAW CHUCK
STEADY REST
5C LEVER TYPE COLLET CLOSER & NOSE PIECE
TOOLPOST
JACOBS DRILL CHUCK FOR TAILSTOCK
THREAD DIAL INDICATOR
FOOT BRAKE
REMOVABLE CHIP PAN
COOLANT SYSTEM WITH SPLASH GUARD
5 HORSE POWER MAIN MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
