Brother TC-32BN QT UNIVERSAL 5-AXIS MACHINING CENTER

Price on Request

Make:: Brother

Model:: TC-32BN QT

Year:: 2016

Ref #:: 163687

Or call us for a quote at (973) 497-7500 or send us an email at cncmachines@machineryvalues.com

BROTHER (WITH TWO-FACE PALLET CHANGER) 5-AXIS CNC DRILL & TAP CENTER
MODEL: TC-32BN QT, NEW: 2016 (2 MACHINES AVAILABLE)

SPECIFICATIONS:
X AXIS TRAVEL .................................. 21.7”
Y AXIS TRAVEL .................................. 15.7”
Z AXIS TRAVEL .................................. 16.3”
DISTANCE BETWEEN TABLE TOP & SPINDLE NOSE END .. 25.4”
WORK AREA SIZE ................................. 23.6” X 16.7” (ONE SIDE)
MAXIMUM LOADING CAPACITY (UNIFORM LOAD) ........ 441 LBS (ONE SIDE)
SPINDLE SPEED .................................. 16-16,000 RPM
SPEED DURING TAPPING ........................... MAX 8000 RPM
TAPERED HOLE ................................... #30
RAPID TRAVERSE RATE X X Y X Z AXES ............. 2755 IPM
CUTTING FEED RATE .............................. 0.04 – 787 IPM
TOOL SHANK TYPE ................................ BT30
TOOL STORAGE CAPACITY .......................... 40 ATC
MAX. TOOL LENGTH ............................... 7.9”
TOOL TO TOOL ................................... .9 SEC
CHIP TO CHIP ................................... 2.0 SEC
MAIN SPINDLE MOTOR (10MIN./CONTINUOUS) ......... 13/10 HP
MACHINE HEIGHT ................................. 93”  (ROBOT NOT INCLUDED)
REQUIRED FLOOR SPACE (w/ CONTROL DOOR OPENED) .. 75” X 145” (ROBOT NOT INCLUDED)
MACHINE WEIGHT ................................. 10,000 LBS  (ROBOT NOT INCLUDED)


EQUIPPED WITH:
CNC-B00 CNC CONTROL
DUAL PALLET
NIKKEN TILTING ROTARY TABLE ON ONE SIDE AND A HYDRAULIC POWER PAC ON THE OTHER
40 ATC
BT30
16,000 RPM SPINDLE
NACHI ROBOT FOR LOADING AND UNLOADING
MANUAL PULSE GENERATOR
WORK LIGHT KIT (2) LIGHTS WITH BRACKETS
EXTENDED I/O BOARD 32/32 (PNP)
FLUME SYSTEM FOR TC-32BN
JET STREAM MINI JET 1000PSI CTS PUMP
AMANO MZ-15 MIST COLLECTOR
RENISHAW OMP40-2 OTS PACKAGE,
NACHI MZ07L FROM AUTOMATION
ATLAS 5C ROTARY
HYDRAULIC POWER PACK, P/N YZ-0004
NIKKEN 5AX-130BAYA-BR-QT
NIKKEN CUSTOM SUB PLATE
FRAMING TO INCLUDE GRAVITY FEED, FLIP STATION, AND ENCLOSURE
QUICK CHANGE MOUNTING
END OF ARM TOOLING
ADAPTOR PLATE FOR NIKKEN INDEXER TO ATLAS 5C CHUCK
PNEUMATICS 5C CHUCK CONTROL AND VALVE
COLLET STOP FOR BAR STOP
HYDRAULIC HOSE AND FITTINGS
WIRE SET FOR HYDRAULIC POWER UNIT
CONTROL RELAY AND WIRING FOR HYDRAULIC CONTROL
TWO IDENTICAL MACHINES AVAILABLE
