Bullard 42" CUTMASTER VERTICAL BORING MILLS & VERTICAL TURRET LATHES

Price on Request

Make:
Bullard
Model:
42" CUTMASTER
Year:
1950
Ref #:
161096

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


42" BULLARD VERTICAL BORING MILL
MODEL: CUTMASTER, S/N: 25599, NEW: 1950

SPECIFICATIONS:
TABLE DIAMETER ........................... 42"
MAX SWING SIDE HEAD IN WORKING POSITION .. 45"
MAX SWING SIDE HEAD BELOW TABLE TOP ...... 54"
CENTERLINE - TABLE TO FACE OF CROSSRAIL .. 14"
CENTERLINE - TABLE TO FACE OF BED ........ 22"
MAX HEIGHT TURRET FACE TO TABLE .......... 48-1/4"
VERTICAL TRAVEL TURRET HEAD SLIDE ........ 30-1/2"
MAX HEIGHT UNDER CROSS RAIL .............. 37"
VERTICAL TRAVEL CROSS RAIL ............... 25"
SIDE HEAD VERTICAL TRAVEL ................ 37-1/4"
SIDE HEAD HORIZONTAL RAM TRAVEL .......... 21"
SWIVEL OF TURRET HEAD .................... +/- 30 DEGREE
TABLE SPEEDS (20) ........................ 5.5 - 200 RPM
FEEDS (16) ............................... .004-.333 IPM
APPROX WEIGHT: 35,700 LBS
FLOOR SPACE:
     114" L-R
     104" F-B
     116-1/2" HIGH w/ HEAD AND RAIL IN LOW POSITION:
     145" HIGH WITH HEAD AND RAIL IN HIGH POSITION

EQUIPPED WITH:
3-JAW CHUCK
SWIVEL PENTAGON TURRET HEAD ON RAIL
SIDE HEAD
T.D.A. UNIT THREAD CUTTING, DRUM SCORING OR ANGULAR TURNING
POWER RAPID TRAVERSE
PENDANT CONTROL WITH TABLE SPEED SHIFTING
30 HORSE POWER MAIN DRIVE MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
