Clausing 2274 Vari-Speed SINGLE SPINDLE DRILL PRESSES

$2,750

Make:
Clausing
Model:
2274 Vari-Speed
Year:
1980's
Ref #:
159042

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


20" CLAUSING VARIABLE SPEED DRILL PRESS
MODEL: 2276, S/N: 506628, MFG: 1970'S

SPECIFICATIONS:
CAPACITY, HAND FEED ................... 1-1/4" DIA
DRILLS TO CENTER OF CIRCLE ............ 20" DIAMETER
WORKING SURFACE OF TABLE .............. 19-1/2" X 22"
SPINDLE TAPER ......................... #3 MORSE
SPINDLE TRAVEL ........................ 6-1/2"
MAX DISTANCE SPINDLE TO TABLE ......... 33-1/8"
MAX DISTANCE SPINDLE TO BASE .......... 43-3/8"
BASE WORKING SURFACE .................. 13" X 15-1/2"
SPINDLE SPEEDS VARIABLE ............... 300 - 2,000 R.P.M.
POWER DOWNFEED RATES .................. .004, .006, .009 & .012 IPR
APPROXIMATE WEIGHT .................... 640 LBS.


EQUIPPED WITH:
* MANUALLY OPERATED RATCHET-TYPE MECHANISM FOR RAISING/LOWERING OF TABLE
* FORWARD & REVERSE SWITCH
* T-SLOTTED TABLE & BASE
* 1-1/2 HORSE POWER SPINDLE DRIVE MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
