Clausing 4VBSCNC40 CNC VERTICAL MILLING MACHINES, NO ATC

$21,500

Make:
Clausing
Model:
4VBSCNC40
Year:
2008
Ref #:
161018

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


CLAUSING 3-AXIS CNC BED MILL w/HAND WHEELS
MODEL: 4VBSCNC40,  S/N: 081218,  NEW: 2008

SPECIFICATIONS:
TABLE SIZE ........................ 10" x 50"
TABLE TRAVEL (X) .................. 29.8"
SADDLE TRAVEL (Y) ................. 19.6"
VERTICAL HEAD TRAVEL (Z) .......... 18.5"
QUILL TRAVEL ...................... 5"
SPINDLE NOSE TO TABLE ............. 3.15" - 22.83"
SPINDLE TAPER ..................... #40 NST
SPINDLE CENTER TO COLUMN FACE ..... 17.3"
HEAD SWIVEL LEFT & RIGHT .......... 90 DEGREES
SPINDLE SPEED RANGE ............... 70 - 4300 RPM
QUILL FEEDS (3) ................... .002, .004, .006 IPR
MAXIMUM WORKPIECE WEIGHT .......... 1,500 LBS
APPROX DIMENSIONS ................. 72"W x 66"D x 80"H
MACHINE WEIGHT .................... 4,400 LBS

EQUIPPED WITH:
ACU-RITE MILLPOWER THREE AXIS CONTROL
    THREE-AXIS SIMULTANEOUS INTERPOLATION INCLUDING
    HELICAL, CANNED CYCLES, GRAPHICS & MUCH MORE
    IN MANUAL MODE 3-AXIS DRO
ACU-RITE GLASS SCALES
QUILL DIGITAL READOUT (Z IS HEAD UP & DOWN NOT QUILL)
SQUARE BOX WAYS - HARDENED & GROUND
PRECISION BALL SCREWS
POWER DRAW BAR
COOLANT SYSTEM
AUTOMATIC LUBRICATION SYSTEM
BELOWS WAY COVERS
5 HORSE POWER SPINDLE MOTOR

TRANSITION FREELY FROM 3-AXIS CNC TO MANUAL
PERFECT FOR A TOOLROOM OR PROTO-TYPE WORK
