Watch Video:

Clausing-Metosa C2087 SS ENGINE LATHES

$15,500

Make:
Clausing-Metosa
Model:
C2087 SS
Year:
2000
Ref #:
160795

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com


20"/30" X 87" CLAUSING-METOSA
GAP BED ENGINE LATHE
MODEL: C2087SS, S/N: 39744, NEW: 2000

SPECIFICATIONS:
SWING OVER BED ....................... 20-7/8"
SWING INSIDE REMOVABLE GAP ........... 30-3/4"
SWING OVER CROSS SLIDE ............... 12-3/4"
DISTANCE BETWEEN CENTERS ............. 87"
SPINDLE BORE ......................... 3-5/32"
SPINDLE NOSE ......................... D1-8"
SPINDLE TAPER ........................ #5 MORSE
WIDTH OF BED ......................... 13-3/4"
SPINDLE SPEEDS (12) .................. 30 - 1500 RPM
LONGITUDINAL FEED RANGE (55) ......... 0.0018 - 0.052 IPR
CROSS FEED RANGE (55) ................ 0.0005 - 0.015 IPR
THREADING RANGE ENGLISH (44) ......... 2 - 60 TPI
THREADING RANGE METRIC (44) .......... .5 - 15 MM
TAILSTOCK SPINDLE TRAVEL ............. 7"
TAILSTOCK SPINDLE TAPER .............. #5 MORSE
APPROXIMATE DIMENSIONS ............... 135"L x 40"W x 54"H
APPROXIMATE WEIGHT ................... 5,750 LBS

EQUIPPED WITH:
- INCH & METRIC THREADING CAPABILITY
- NEWALL TWO AXIS DIGITAL READOUT
- TAPER TURNING ATTACHMENT
- 12" 3-JAW ATLAS CHUCK
- QUICK CHANGE TOOLPOST
- THREAD DIAL INDICATOR
- FULL LENGTH BACK SPLASH GUARD
- COOLANT PUMP AND TANK
- 10 HORSE POWER MAIN MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE


DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
