Harig Super 612, 1981, SURFACE GRINDERS, HAND FEED

Price on Request

Make:: Harig

Model:: Super 612, 1981,

Year:: 1981

Ref #:: 178279

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

    6" X 12" HARIG (MADE IN USA)
"PRECISION" HAND FEED SURFACE GRINDER

MODEL: 612    S/N: 13765    NEW: 1981

WIDTH AND LENGTH GROUND ................ 6" X 12"
LONGITUDINAL TRAVEL .................... 12-3/4"
CROSS FEED TRAVEL ...................... 6-3/4"
VERT. WORKING HEIGHT UNDER 7" WHEEL .... 12"
MAXIMUM GRINDING WHEEL DIAMETER ........ 8"
ELEVATING HANDWHEEL GRAD. .............. 0.0005"
CROSS FEED HANDWHEEL GRAD. ............. 0.001"
FINE FEED HANDWHEEL FOR CROSS, GRAD. ... 0.0001"
SPINDLE SPEED .......................... 3,450 RPM

FLOOR AREA CABINET .................. 21" x 25"
FLOOR AREA OPERATING SPACE .......... 48" x 45"
APPROXIMATE MACHINE WEIGHT .......... 900 LBS

EQUIPPED WITH:
HARIG 1.5 HP DIRECT DRIVE "CARTRIDGE TYPE"
  SPINDLE, ELECTRICS ARE 3/60/208-230-460 VOLTS
"HIGH SPEED STEEL HAREDENED WAYS" OPTION
V AND FLAT WAY CONSTRUCTION
CABLE DRIVE FOR LONGITUDINAL TABLE MOVEMENT
HARIG "FLO-CLEAN" AUTOMATIC LUBRICATION SYSTEM
6" X 12" "O.S. WALKER" "CERAMAX",
   FINE-DIVISION PERMANENT MAGNETIC CHUCK
WORK LIGHT
MACHINE IS PRESENTLY WIRED FOR 3/60/208 VOLTS


* INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE *
** SUPERB CONDITION & APPEARANCE **
