Jones & Shipman Easy 650 UNIVERSAL CYLINDRICAL GRINDERS

Price on Request

Make:
Jones & Shipman
Model:
Easy 650
Year:
2010
Ref #:
158551

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com


  12.5" x 25.5" JONES & SHIPMAN "HIGH PRECISION" "FANUC" MICROPROCESSOR CONTROLLED
            UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER

  (MADE IN GREAT BRITIAN, NOW A DIVISION OF HARDINGE)

MODEL: SUPREMA EASY 650


Table:
Swing:....................................... 12.5"
Distance Between Centers:.................... 25.5"
Table Travel ................................ 29.5"
Max. Traverse Speed ......................... 472" IPM
HPG Increments .............................. 0.00005", 0.0005", or 0.005"
Table Swivel ................................ 18 Deg. CCW, 16 Deg. CW



Wheelhead:
Total Infeed Travel:......................... 10.236""
Max. Speed .................................. 236" IPM
Minimum Programmable Increment .............. 0.00005"
HPG Increments .............................. 0.00005", 0.0005", or 0.005"
Swivel Range ................................ 190 Degrees CW
                                              45 Deg. CCW


External Grinding Wheels:
Grinding Wheel Size, L.H. Standard:.......... 14" x 2"W x 5"B
                     R.H Standard: .......... 12" x 1"W x 5"B
Spindle Speeds (3):.......................... 1773, 2069 & 2400 RPM
Motor Power: ................................ 5.5 H.P.


Headstock:
Swivel:...................................... 15 Degrees CW
                                              90 Deg. CCW
Speed, Infinitely Variable:.................. 30 to 450 RPM
Centers, Standard/Reduced ................... #5 MT/#3 MT

Approximate Weight: ......................... 11,000 Lbs.




  Equipped with:

Table and wheelhead driven by AC digital servo motors,
  preloaded ballscrews& rotary encoders.

"GE Fanuc Quickpanel" Microprocessor Control - Touch Control Panel
  is from a unique, operator compatible, touch key panel,
  that's easy to use and, because of faster set ups,
  enables a higher level of grinding performance."

 Standard Control Features
Manual, semi automatic or fully automatic operation modes
From 1-20 cycles can be combined in automatic mode
Machine can come in a do Multi-Diameters (Multi Plunge & Pick Operations)
 in one set up
Simple & Rapid Set up for Automatic Grind Cycles
Manual traverse grind
Manual straight dress
In-cycle interrupt, edit & recovery
Simple trimming of diamond or grind positions
Regrind facility
Use of new or preformed wheels
In Cycle, or Out of Cycle or no Dressing for vitrified
 and plated wheels In Cycle or Out of Cycle Dressing
 with Full Compensation Dress on Demand with Full Compensation

"Grinding cycles are very easy to program, using step
  by step parameter prompting with default values
  which can be accepted or amended as required.
  At the end of a cycle the wheel retracts automatically.
  For manual operation, precise control of table traverse
  and wheelfeed is by hand pulse generators (HPG's) and
  the position of each axis is clearly indicated on digital
  readouts, which also display parameters."

Machine can do up to 20 Different operations through the control
 in one grind.  Multi-Plunge on a part, traverse grind, dress the
 wheel, rapid in & out, sparkout time, all in one set up.

Automatic Dressing of the grinding wheel with automatic
  wheel compensation.


Low friction coated guideways on the table and wheelhead
  axes.

AC variable speed headstock motor with #5 MT/#3 MT center
  adapter.

Adjustable spring loaded tailstock with #3 Morse Taper center

External coolant system, with tank, pump, and paper band
  filtration.

Three Wheelhead Design, L.H. Standard, R.H. Standard
  and Swing Around Internal Grinding, complete
  with internal grinding spindle.

Accessories Included




** Inspect Under Power in our Harrison, NJ Warehouse **
