Milltronics MB20 CNC VERTICAL MILLING MACHINES, NO ATC

$15,500

Make:
Milltronics
Model:
MB20
Year:
1999
Ref #:
159866

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


MILLTRONICS 3-AXIS CNC BED MILL
MODEL: MB20 D, S/N: 5619, NEW: 1999

SPECIFICATIONS:
TABLE SIZE.............................. 16" X 54"
LONGITUDINAL TABLE TRAVEL(X)............ 38"
CROSS TABLE TRAVEL(Y)................... 20"
VERTICAL HEAD TRAVEL(Z)................. 24"
SPINDLE QUILL TRAVEL.................... 6"
QUILL FEEDS (3) ........................ .0017, .0032 & .0053 IPR
SPINDLE QUILL DIAMETER.................. 4.125"
SPINDLE TO COLUNM....................... 20"
SPINDLE TO TABLE........................ 2" TO 26"
TABLE LOAD CAPACITY..................... 2,000 LBS.
SPINDLE SPEEDS PROGRAMMABLE............. 60 TO 4,000 RPM
SPINDLE TAPER........................... #40 STD
FEEDRATE RANGE ......................... 0 - 200 IPM
RAPID TRAVERSE RATE .................... 250 IPM
SHIPPING DIMENSIONS..................... 88" X 80" X 99"
MACHINE WEIGHT.......................... 6000 LBS


EQUIPPED WITH:
  * CENTURION VI 4-AXIS CNC CONVERSATIONAL CONTROL
  * FULL 4-AXIS SIMULTANEOUS CNC
  * RS 232 & DNC
  * ENGRAVING PACKAGE
  * LCD COLOR MONITOR
  * POWER DRAW BAR
  * HARDENED & GROUND BOX WAYS ON SADDLE & COLUMN
  * COOLANT SYSTEM WITH CHIP PAN
  * HANDWHEELS ON X & Y AXIS FOR MANUAL OPERATION
  * BALLSCREWS& SERVO DRIVES FOR X,Y & Z TRAVELS
  * 10 HORSE POWER SPINDLE WITH INVERTER DRIVE

INSPECT UNDER POWER IN A MIDWEST WAREHOUSE
