Watch Video:

Milltronics RH20 VERTICAL MACHINING CENTERS. VMC's

$34,500

Make:: Milltronics

Model:: RH20

Year:: 2015

Ref #:: 169153

Or call us for a quote at (973) 497-7500 or send us an email at cncmachines@machineryvalues.com

MILLTRONICS VERTICAL MACHINING CENTER
MODEL: RH-20,  S/N: 12975,  NEW: 2015

SPECIFICATIONS:
TRAVELS:
  X AXIS TRAVEL ....................... 40"  1015mm
  Y AXIS TRAVEL ....................... 20"  510mm
  Z AXIS TRAVEL ....................... 23"  610mm
TABLE WORKING SURFACE ................. 16" X 54"
MAXIMUM WORK PIECE WEIGHT ON TABLE .... 2500 LBS
SPINDLE TO TABLE MIN / MAX ............ 2" - 26"
COLUMN TO SPINDLE CENTER .............. 21"
INFINITELY VARIABLE SPINDLE SPEEDS .... UP TO 8,000
SPINDLE TAPER ......................... 40 CAT
TOOL CHANGER .......................... 24 ATC
APPROX. OPERATING DIMENSIONS .......... 129"W x 78"D x 103"H
APPROXIMATE WEIGHT .................... 8,000 LBS

EQUIPPED WITH:
- MILLTRONICS MODEL: CENTURIAN 8200 3-AXES CNC CONTROL
  W/ CONVERSATIONAL OR G CODE PROGRAMMING,
  COLOR LCD, PENDANT MOUNT, USB PORT
- RIGID TAPPING, MACROS
- HELICAL INTERPOLATION, ROTATION & SCALING
- TELESCOPIC WAY COVERS
- 24 POSITION AUTOMATIC TOOL CHANGER
- SELF CONTAINED FLOOD COOLANT
- AC SPINDLE & AXIS DRIVES
- 24/15 HORSE POWER SPINDLE DRIVE MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
