Sharp HMV w/Prototrak AGE 2 Control CNC VERTICAL MILLING MACHINES, NO ATC

$7,950

Make:
Sharp
Model:
HMV w/Prototrak AGE 2 Control
Year:
1998
Ref #:
159147

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


SHARP PROTO-TRAK 2-AXIS CNC VERTICAL MILL
MODEL: HMV with PROTOTRAK AGE 2
  S/N: 70201033,  NEW: 1998

SPECIFICATIONS:
WORKING SURFACE OF TABLE ................. 10" x 51"
LONGITUDINAL TABLE TRAVEL ................ 33"
CROSS TABLE TRAVEL ....................... 15"
QUILL TRAVEL ............................. 5"
KNEE TRAVEL .............................. 17"
MAXIMUM TABLE LOAD ....................... 880 LBS.
SPINDLE TAPER ............................ #30
VARIABLE SPINDLE SPEEDS .................. 60 TO 4200 RPM
SPINDLE FEEDS(3) ................... .0015, .003, .006" IPR
FLOOR SPACE: ............................. 106" x 72" x 89"
WEIGHT APPROXIMATELY: .................... 3,500 LBS.

EQUIPPED WITH:
SOUTHWESTERN INDUSTIRIES, PROTO-TRAK AGE 2-AXIS CNC CONTROL
   WITH SERVO MOTORS, MANUAL DATA INPUT 2 AXIS
   LINEAR& CIRCULAR INTERPOLATION, PROGRAM DOWNLOAD,
   BOLT HOLE PATTERNS, PART GRAPHICS
GLASS SCALES
IN MANUAL OPERATION, CONTROL BECOMES 3 AXIS DIGITAL READOUT
GROUND BALLSCREWS ON TABLE & SADDLE
HARDENED & CHROMED DOVETAILED SADDLE WAYS
BOX COLUMN WAYS
KURT POWER DRAW BAR
LUBRICATION SYSTEM
COOLANT SYSTEM
3 HORSE POWER SPINDLE MOTOR

TRANSITION FREELY FROM 2-AXIS CNC TO MANUAL.
PERFECT FOR A TOOLROOM OR PROTO-TYPE WORK

CONDITION - EXCELLENT!

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE.
