Watch Video:

South Bend NORDIC 25 ENGINE LATHES

$18,500

Make:
South Bend
Model:
NORDIC 25
Year:
1980's
Ref #:
163757

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com


25"/34" x 60" SOUTHBEND GAP BED LATHE
MODEL: NORDIC-25,  NEW: 1980'S

SPECIFICATIONS:
SWING OVER BED WAYS ................. 25"
SWING IN REMOVABLE GAP .............. 34"
SWING OVER CROSS SLIDE .............. 15-3/4"
DISTANCE BETWEEN CENTERS ............ 60"
HOLE THRU SPINDLE ................... 2-3/4"
SPINDLE NOSE CAMLOCK ................ D1-8"
WIDTH OF BED ........................ 17-3/4"
SPINDLE SPEED RANGE (18) ............ 18 - 1400 RPM
LONGITUDINAL FEED RANGE (25) ........ .0028" - .045"
CROSS FEED RANGE (25) ............... .0014" - .0225"
INCH THREADING RANGE ................ 35/128 - 64 TPI
METRIC THREADING RANGE .............. .625 - 128 mm
TAILSTOCK SPINDLE TRAVEL ............ 7-7/8"
TAILSTOCK SPINDLE TAPER ............. #5MT
APPROXIMATE FLOOR SPACE ............. 140"L x 42"W x 59"H
APPROX WEIGHT ....................... 7,500 LBS

EQUIPPED WITH:
INCH & METRIC THREADING
REMOVEABLE GAP
TAPER ATTACHMENT
3-JAW CHUCK
4-JAW CHUCK
KDK QUICK CHANGE TOOLPOST
ROLLER TYPE STEADY REST
THREAD DIAL INDICATOR
COOLANT SYSTEM
HARDENED & GROUND BED WAYS
15 HORSE POWER MAIN MOTOR

INSPECT UNDER POWER IN A WEST COAST WAREHOUSE
