Citizen M-12 2M3 CNC SWISS TYPE MULTI-AXIS LATHES

$19,500

Make:
Citizen
Model:
M-12 2M3
Year:
1999
Ref #:
162363

Or call us for a quote at (973) 497-7500 or send us an email at automatics@machineryvalues.com


CITIZEN M-12 (2M3) CNC SWISS SCREW MACHINE
NEW: 1999


General Specifications:
CNC Control:                                        Mitsubishi (M6M)

Machining Diameter:                                 1/2"
Machining Length per Chucking:                      7 3/4" (200mm)
Drilling Diameter:                                  6mm Maximum Threading

Diameter (tap & die):                               M6
Main Spindle Speed:                                 200 - 12000 rpm
Main Spindle Indexing:                              Full C-Axis
Rotary Spindle on Gang Tool Post:
   Drilling Diameter:                               5mm (Tapping M4)
Spindle Speed:                                      200 - 8000 rpm
Rotary Spindle on Tool Turret Head:
   Drilling Diameter:                               5mm
   Threading Diameter:                              M5
   Spindle Speed:                                   200 - 6500 rpm
Backwork:
   Chucking Diameter of Backwork Spindle:           1/2"
   Backwork Length:                                 125mm
   Drilling Diameter:                               5mm
   Threading Diameter:                              M5
   Backwork Spindle Speed:                          250 - 6000 rpm
   Spindle Indexing:                                Full C-Axis
Number of Installable Tools:
   Gang Tooling:                                    5 Turning, 3 Rotary
   Turret Tooling:                                  10 Tools
   Number of Turret Indexes:                        10 sets (20 sets avail.)
   Back Work Tool Post:                             3
Tool Sizes:
   Gang Tooling:                                    10mm x 10mm x 120mm
   Turret Tooling:                                  10mm x 10mm x 60mm
   Sleeve Size:                                     19.05mm diameter
Motors:
   Main Spindle Drive:                              1.5/2.2kw
Power Supply:                                       6 kva
Dimensions (approx.):                               97" x 49" x 68"h
Weight (approx.):                                   4840 lbs.
Machine:  96" x 45" x 89" 5,000 lbs

Equipped With:
   Cincom CNC  Control
   Iemca Mini Boss 325 Magazine Bar Feed


DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
