Dake 5-075 Elecdraulic HYDRAULIC H-FRAME PRESSES

$5,950

Make:: Dake

Model:: 5-075 Elecdraulic

Year:

Ref #:: 177932

Or call us for a quote at (973) 497-7500 or send us an email at presses@machineryvalues.com


75 TON DAKE H-FRAME ELEC-DRAULIC HYDRAULIC PRESS
MODEL 5-075

RATED CAPACITY ............................ 75 TONS
WIDTH BETWEEN UPRIGHTS .................... 44"
WIDTH BETWEEN TABLE CHANNELS .............. 8-1/4"
SPPED ...................(ADVANCE)......... 28 IPM
       ...................(PRESS).......... 5 IPM
MINIMUM RAM TO TABLE ...................... 6"
MAXIMUM RAM TO TABLE ...................... 36"
RAM TRAVEL ................................ 10"
HORIZONTAL WORKHEAD TRAVEL ................ 24"

EQUIPPED WITH:
- ELECTRIC OPERATION FOR SMOOTH CONSISTENT PRESSING ACTION
- SINGLE ACTING CYLINDER
- RAPID RAM APPROACH, QUICKLY MOVES RAM TO TO WORK TO SAVE ON PRODUCTION TIME
- VARIABLE RAM SPEED
- MOVEABLE WORKHEAD FOR OFF-CENTER WORK
- RAPID RAM RETURN
- SAFETY VALVE, PROTECTS AGAINST OVERLOADS
- STROKE INDICATOR, ENSURES ACCURATE RAM CONTROL
- ADJUSTABLE TABLE WITH SELF LOCKING TABLE HOIST
- 2 HP, 1800 RPM MOTOR, 208/230/460 VOLT 3 PHASE

OVERALL DIMENSIONS: 55-1/2" X 36" X 86" H, WT. 1,650#
