Mark 1020AH SURFACE GRINDERS, HYDRAULIC

Price on Request

Make:: Mark

Model:: 1020AH

Year:

Ref #:: 139060

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

										NEW MARK PRECISION SURFACE GRINDER
 MODEL:   1020-AH - 2 AXIS Hydraulic

 CAPACITY
 Nominal grinding length: 20"
 Nominal grinding width: 10"
 Maximum distance: table to spindle center: 19.3"

 TABLE
 Table travel (cross x longitudinal): 11" x 27.6"
 Spindle center to table surface: 19.3"
 Table working surface: 9" x 19.7"
 Longitudinal hydraulic table feed: 6.6 - 82 FPM
 Intermittent cross feed (in. feed): 0.004 - 0.4 IPM
 Continuous cross feed: 39 IPM
 Number of graduations on dial: 200
 Feed per graduation: 0.0005"
 Feed per revolution: 0.1"

 VERTICAL TRAVEL
 Number of graduations on dial: 500
 Feed per graduation: 0.0001"
 Feed per revolution: 0.05"
 Rapid downfeed (optional): 18.9 IPM

 SPINDLE AND WHEEL
 Wheel size (OD x W x ID): 14 x 1 x 5"
 Spindle motor: 3 hp

 GENERAL
 Coolant system: 1/8 hp
 Approximate weight: 3,800 lbs
 Packing crate dimensions (W x D x H): 7 x 5 x 6'

 STANDARD EQUIPMENT:
 Grinding Wheel
 Wheel Flange
 Coolant System with guarding
 Wheel Balancer and Balancing arbor
 Automatic Lubrication System
 Tool kit

 OPTIONAL (EXTRA COST) ACCESSORIES
 Permanent magnetic chuck - coarse or fine pole (Kanetsu)
 Electro-magnetic chuck with control (Kanetsu or Walker)
 Spare wheel adaptors
 Coolant system with paper and magnetic filtration
 Dust collector
 Parallel or Radius dressers
 Wheel Balancing stand
 Push-Button Rapid Up & Down Wheelhead
 Programmable Microprocessor IDF Control w/CRT Display
