Romi C620 CNC LATHES, FLAT BED (ENGINE LATHE STYLE)

$47,500

Make:
Romi
Model:
C620
Year:
2012
Ref #:
162153

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com



ROMI CNC FLAT BED MANUAL/TEACH LATHE
MODEL: C620,  S/N: 016-015183-459,  NEW: 2012

SPECIFICATIONS:
SWING OVER BED......................... 24.41"
DISTANCE BETWEEN CENTERS............... 80"
SWING OVER CROSS SLIDE................. 13.62"
SWING OVER SADDLE WINGS................ 21.26"
SLIDE TRAVEL IN/OUT (X-AXIS)........... 14.17"
CARRIAGE TRAVEL (Z-AXIS)............... 78.74"
BED WIDTH.............................. 14.96"
SPINDLE NOSE........................... A2-8"
SPINDLE BORE........................... 3.15"
SPEED RANGES (2 SPEED GEARBOX)......... 1 TO 2,500 RPM
RAPID TRAVERSE RATE.................... 315 IPM
MAIN SPINDLE MOTOR..................... 25 HP
APPROXIMATE MACHINE WEIGHT............. 12,200 LBS

EQUIPPED WITH:
* SIEMENS 802D SL PRO CNC CONTROL WITH CONVERSATIONAL PROGRAMMING
NO G-CODE EXPERIENCE NECESSARY
* 2-ELECTRONIC HAND WHEELS WITH TEACH-IN MODE
* REMOTE JOG HANDLE
* SPINDLE ORIENTATION * RIGID TAPPING
* USER CREATED MACROS * 3 MB PROGRAM MAMORY * THREAD REPAIR CYCLES
* USB, EITHERNET AND COMPACT FLASH PORTS
* ADVANCED INTUTITIVE PROGRAMMING SYSTEM
* QUICK CHANGE TOOLPOST
* TAILSTOCK WITH ADJUSTABLE QUILL
* COOLANT SYSTEM
* FULLY ENCLOSED SPLASH GUARD
* 10" 3-JAW CHUCK

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
