Southwest Ind. 1630 SX CNC LATHES, FLAT BED (ENGINE LATHE STYLE)

$16,750

Make:: Southwest Ind.

Model:: 1630 SX

Year:: 2008

Ref #:: 169266

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

16" X 30" TRAK 2-AXIS CNC/MANUAL FLAT BED LATHE
MODEL: 1630-SX, S/N: 081CH16153, NEW: 2008

SPECIFICATIONS:
HEIGHT OF CENTERS .......................... 8"
SWING OVER BED ............................. 16"
SWING OVER CROSS SLIDE ..................... 8.6"
SWING OVER SADDLE WINGS .................... 16"
MAX DISTANCE BETWEEN CENTERS ............... 30"
CROSS SLIDE TRAVEL (X) ..................... 8.5"
LONGITUDINAL TRAVEL (Z) .................... 30"
SPINDLE TAPER, CAMLOCK, SIZE ............... D1-6"
SPINDLE SPEED RANGE INF VAR ................ 150 - 2500 RPM
SPINDLE BORE ............................... 2.12"
TAPER IN HEADSTOCK SPINDLE ................. #5 MT
WIDTH OF BED ............................... 12.6"
TAILSTOCK QUILL TRAVEL ..................... 5.75"
TAILSTOCK QUILL DIAMETER ................... 2.36"
TAILSTOCK QUILL TAPER HOLE ................. #4 MT
APPROX WEIGHT .............................. 2500 LBS
APPROX DIMENSIONS .......................... 82" X 46" X 67"

EQUIPPED WITH:
- SOUTHWESTERN INDUSTRIES-PROTOTRAK MODEL: SLX CNC CONTROL
   OPTIONS: ADVANCED FEATURES, NETWORK, & TRAKING
- TWO AXIS DIGITAL READOUT DURING MANUAL OPERATION
- CONSTANT SURFACE SPEED & PROGRAMMABLE SPINDLE SPEEDS
- SERVO MOTORS & GROUND BALLSCREWS
- AC SPINDLE DRIVE
- ELECTRONIC HANDWHEELS FOR X & Z MANUAL TRAVERSE
- JOGSTICK FOR CONVENIENT JOG AT RAPID TRAVELS
- INCH & METRIC THREADING CAPABILITY
- ALORIS QUICK CHANGE TOOLPOST
- 6-JAW BUCK CHUCK
- HARDENED & GROUND BED WAYS
- AUTOMATIC CENTRAL LUBRICATION SYSTEM FOR THE SLIDE WAYS & BALLSCREWS
- COOLANT PUMP w/ REAR SPLASH GUARD
- 7.5 HORSE POWER 3/60/230 VOLT SPINDLE DRIVE MOTOR & ELECTRICAL CONTROLS
