Myford MG12-SME, NEW 1990, SWING DOWN I.D., PLAIN CYLINDRICAL GRINDERS

Price on Request

Make:
Myford
Model:
MG12-SME, NEW 1990, SWING DOWN I.D.,
Year:
1990
Ref #:
159991

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com


  5" X 12" MYFORD HIGH-PRECISION "MADE IN ENGLAND"
  I.D./O.D. CYLINDRICAL GRINDER WITH HYDRAULIC TABLE FEED

** MYFORD SWING DOWN I.D. GRINDING ATTACHMENT WITH I.D. SPINDLE **

MODEL: MG12-ME      S/N: SME 163994      NEW: 1990

MAXIMUM GRINDING DIAMETER ............... 3"
SWING OVER TABLE ........................ 5"
CAPACITY BETWEEN CENTERS ................ 12"
MAXIMUM TABLE TRAVEL .................... 13-3/8"
TABLE SWIVELS EITHER WAY ................ 7 DEGREES
TABLE TRAVEL PER REV. OF HANDWHEEL ...... 0.51"
TABLE SPEEDS BY HYDRAULIC POWER ......... 0 TO 180" IPM
DWELL (CARRIAGE) ........................ 0.8 SECS.

  WHEELHEAD
(ALL GRADUATIONS, ON WORK DIAMETER):
TOTAL TRAVEL BY FEED SCREW .............. 3-7/8"
INFEED PER REV. OF HANDWHEEL ............ 0.04"
WHEEL FEED GRADUATION ................... 0.0002"
FINE FEED TO DEAD STOP .................. 0.00005"
WHEEL SPEEDS (2) ........................ 1830 & 1988 RPM
GRINDING WHEEL .......................... 12" X 1-1/2" X 5"
MIN. WHEEL DIA. FOR ZERO WORK DIA.  ..... 10"

  WORKHEAD:
SPINDLE SPEEDS, INFINITELY VARIABLE ..... 50 TO 900 RPM
CAPACITY THRU STANDARD DRAW TUBE ........ 3/4"
MAXIMUM COLLET CAPACITY ................. 3/4"

APPROXIMATE WEIGHT ...................... 2,200 LBS

  EQUIPPED WITH:
MYFORD SWING DOWN I.D. ATTACHMENT WITH "NAKANISHI" ELECTRONIC
 VARIABLE SPEED I.D. SPINDLE WITH CONTROL BOX
HYDRAULIC LONGITUDINAL FEED
MANUAL INFEED OF THE WHEELHEAD
WORKHEAD W/DUAL LIVE/DEAD SPINDLE
MYFORD 4C COLLET DRAW BAR & ASSORTMENT OF 4C COLLETS
"BUCK" 6-JAW CHUCK & ADAPTOR
MAGNETIC CHUCK MOUNTED ON ADAPTOR
TABLE MOUNTED DRESSER
WORKHEAD PRESENTLY HAS AN ADAPTOR WITH FACE PLATE AND FIXTURE
INFINITELY VARIABLE WORKHEAD SPINDLE SPEEDS
TABLE MOUNTED WHEEL DRESSER
AUTOMATIC LUBRICATION FOR WHEELHEAD AND CARRIAGE WAYS
COOLANT SYSTEM
EXTERNAL HYDRAULIC PUMP (6- 1/2 GALLONS)
3/60/220-440 VOLT MOTORS
MACHINE IS PRESENTLY WIRED FOR 3/60/440 VOLTS


  ** BEAUTIFUL CONDITION & APPEARANCE - ORIGINAL PAINT **
** INSPECT UNDER POWER IN OUR HARRISON, N.J. FACILITY **
