Parker-Majestic 2EA, NEW 1998, PROGRAMMABLE INFEED PLAIN CYLINDRICAL GRINDERS

Price on Request

Make:
Parker-Majestic
Model:
2EA, NEW 1998, PROGRAMMABLE INFEED
Year:
1998
Ref #:
169299

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com



     12" X 30" PARKER-MAJESTIC "HIGH-PRECISION"
     "MADE IN USA" O.D. CYLINDRICAL GRINDER
       WITH "PROGRAMMABLE AUTOMATIC INFEED",
      CAN DO MULTI-DIAMETERS IN ONE CYCLE
        & MINIMUM INCREMENT IS 0.000050"

MODEL: 2EA    S/N: 6272-2EA-98   NEW: 1998



SWING OVER TABLE: .................. 12"
DISTANCE BETWEEN CENTERS:........... 30"
TABLE SWIVEL: ...................... 7°
TABLE SPEEDS, INF. VARIABLE: ....... 3" TO 30"
TABLE WORK SURFACE: ................ 5" X 50"

HEADSTOCK SWIVEL: .................. 90°
HEADSTOCK SPEED (INF. VARIABLE): ... 20 TO 450 RPM
HOLE THRU SPINDLE: ................. 1-1/2"
HEADSTOCK CENTER TAPER: ............ 6# JARNO

CROSS FEED TRAVEL: ................. 3-1/2"
CROSS FEED ADJUSTMENT: ............. 4"
CROSS FEED HANDWHEEL GRADUATED:..... 0.0005"
CROSSFEED PRECISION DIAL GRAD.: .... 0.00005"

DIAMETER OF EXTERNAL SPINDLE: ...... 3"
EXTERNAL GRINDING WHEEL: ........... 12" x 1" x 5"

TAILSTOCK CENTER TAPER: ............ #6 JARNO
TABLE FEED MOTOR: .................. 1/2 HP
WORKHEAD MOTOR: .................... 1/2 HP
SPINDLE DRIVE MOTOR (External) : ... 3 HP @ 1,800 rpm

APPROXIMATE FLOOR SPACE: ........... 41" X 124"
APPROXIMATE WEIGHT: ................ 3,600 LBS

EQUIPPED WITH:

P-M PROGRAMMABLE AUTO CYCLE CONTROL
 - BOTH THE TABLE AND WHEELHEAD ARE DRIVEN BY
    BALL SCREWS, POWERED WITH SERVO MOTORS
 - 0.0000050" (50 MILLIONTHS) PROGRAMMAING INCREMENT
 - MACHINE CAN MULTI-DIAMTERS IN ONE SET-UP/PROGRAM
 - USER FRIENDLY CONTROL

VARIABLE SPEED CONTROL KNOBS FOR WORKHEAD AND
  TABLE SPEED ON OPERATOR CONTROL PANEL
HEAVY DUTY WORKHEAD w/SINE BAR OPTION
SIX JAW CHUCK MOUNTED ON WORKHEAD
HEIDENHAIN 2-AXIS DIGITAL READOUT w/1 MICRON SCALES
COOLANT SYSTEM

Presently wired for 3 phase, 60 Cycles, 480 Volts
Inspect under power in our Harrison, NJ Warehouse
Exceptional Condition & Appearance - Original Paint
