Shigiya GP-30-60F, 1985, MADE IN JAPAN, HAND FEEDS PLAIN CYLINDRICAL GRINDERS

Price on Request

Make:: Shigiya

Model:: GP-30-60F, 1985, MADE IN JAPAN, HAND FEEDS

Year:: 1985

Ref #:: 169293

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

    11.8" X 24" SHIGIYA-OKAMOTO
   (MADE IN JAPAN) "HIGH-PRECISION"
  HAND FEED PLAIN CYLINDRICAL GRINDER

  MODEL: GP30-60F    S/N: 31008     NEW: 1985

SWING ............................... 11.8"
DISTANCE BETWEEN CENTERS ............ 24"
MAX. WORKPIECE WEIGHT,
  BETWEEN CENTERS ................... 286 LBS.
TABLE SWIVELS (TOTAL) ............... 10°
MAX. STROKE OF WHEELHEAD (MANUAL) ... 8.5"
ONE REV. OF HANDWHEEL ............... 0.04"
HANDWHEEL, FINE FEED BY MICRFEED .... 0.0001"

GRINDING WHEEL SIZE ................. 16" DIA. x 1"-3"W
                                       x 5" BORE
GRINDING WHEEL SPEEDS ............... 1,563 RPM
WORKHEAD SPINDLE TAPER .............. #4 MT
WORKHEAD SPINDLE SPEEDS (9) ......... 13 TO 252 RPM
WORKHEAD SWIVELLING RANGE (TOTAL) ... 120 DEG.
TAILSTOCK SPINDLE TAPER ............. #4 MT
TAILSTOCK SPINDLE TRAVEL ............ 1.2"

APPROX. MACHINE WEIGHT .............. 6,000 LBS.



STANDARD FEATURES:
MANUAL FEEDS, NO POWER FEEDS, NO HYDRAULICS
WHEELHEAD FEATURES HYDROSTATIC BEARING DESIGN
 (AUTO-PRESSURE LUBRICATED)
SEPARATE LUBRICATION SYSTEM FOR WHEELHEAD SPINDLE OIL
AUTOMATIC LUBRICATION SYSTEM FOR WAYS
5 H.P. WHEELHEAD MOTOR, 3/60/230-460 VOLTS

MACHINE IS EQUIPPED WITH THE FOLLOWING ACCESSORIES:
2-POINT REST
DOG SET
EXTRA NORTON WHEELS
CENTER IN WORKHEAD
COOLANT SYSTEM
MACHINE IS PRESENTLY WIRED FOR 3/60/220 VOLTS

SPECIAL NOTE:
FOR HIGH-PRECISION WORKPIECES LIKE THOSE FOUND IN
 JIG TOOLS AND DIES.  EXTREMELY ACCURATE.  CAN DO
 HEAVIER PARTS, UP TO 286 LBS. BETWEEN CENTERS.
 HAND FEEDS ONLY ..... LIKE A MYFORD OR A
 CRYSTAL LAKE ON STERIODS!


** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
*** EXCELLENT CONDITION & APPEARANCE (ORIGINAL PAINT) ***
