Unison 288-0000, NEW 2000, C DEDTRU, HARIG 618 BASE CENTERLESS GRINDERS

Price on Request

Make:: Unison

Model:: 288-0000, NEW 2000, C DEDTRU, HARIG 618 BASE

Year:: 2000

Ref #:: 169177

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

  UNISON DEDTRU CENTERLESS GRINDING MACHINE

MODEL: 288-0000    S/N: 9833      NEW: 2000



VERTICAL WORKING HEIGHT (CENTER OF SPINDLE ABOVE)
  REGULATING ROLL ........................ 10"
CROSS FEED TRAVEL ........................ 6-3/4"
LONGITUDINAL TRAVEL ...................... 18"
TABLE SIZE ............................... 6" X 18"
WORKPIECE SIZE:
  O.D. WORK WITH BASIC EQUIPMENT ......... 1/4" TO 1-1/4"
  O.D. WORK W/STD. OPTIONAL ACCESSORIES .. 0.031" TO 5"
  I.D. WORK - MAXIMUM O.D. ............... 5"
MAXIMUM WHEEL DIAMETER ................... 8"
MAXIMUM WHEEL LENGTH ..................... 3"
APPROXIMATE MACHINE WEIGHT ............... 1,500 LBS


EQUIPPED WITH:

   -  UNISON MODEL "C" DED-TRU CENTERLESS GRINDING UNIT,
       -DESIGNED TO DO THROUGH FEED, O.D., I.D. AND
       SECOND OPERATIONS.
     REGULATING ROLL WITH ITS OWN SELF-CONTAINED DC
       DRIVE CONTROLLER. REGULATING ROLL SIZE 4" X 4"

   -  HARIG #618W SURFACE GRINDER BASE, TABLE MODIFIED
     BY UNISON FOR DEDTUR GRINDING UNIT, HOLE THRU
     COLUMN FOR THRUFEED GRINDING, ELECTRICAL PACKAGE,
     ETC.
   - 2-AXIS DIGITAL READOUT
     "POPE" 3 H.P. SPINDLE, 3/60/230-460 VOLT



** INSPECT UNDER POWER IN GRAND RAPIDS, MI **
** EXCELLENT CONDITION & APPEARANCE **
